Chiaravalli right-angle gear drives

Chiaravalli right-angle gear drives offer cutting-edge technology and excellent mechanical solutions to meet the growing needs of an increasingly complex market. The cubic form of the angular gearboxes is practical and allows a universal mounting on each machine. The quickdraws prove to be just as versatile for the choice of shafts and the possibility of direct connection to any type of motor, from IEC standards to brushless, to tires and so on.

Selecting the correct type of angle bevel gear is not simply a question of defining the power required in relation to rpm and the torque to be transmitted. It also involves defining the conditions under which the angle bevel gear will be used. Defining operating conditions involves taking into consideration a number of factor such as the type of operating cycle (intermittent, continuous), radial and axial loads on the shaft ends, maximum and minimum temperatures, ambient conditions (e.g. dust and dirt levels) and the type of lubrificant used.
